Tea Bag Inside And Outside Bag Packaging Machine Tea Herbal Tea Tea Small Granules
Place of Origin | Guangdong,China |
---|---|
Brand Name | ZCHONE PACK |
Certification | ISO,CE |
Model Number | ZC-168 |
Minimum Order Quantity | 1set |
Price | $7,380~$8,300 |
Packaging Details | Standard export wooden case packaging |
Delivery Time | 15 |
Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability | 1/sets/15day |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xType | Multi-Function Packaging Machine | Production Capacity | 50bag/min, 30bag/min, 60bag/min |
---|---|---|---|
Dimension(L*W*H) | 1270 * 860* 1840mm | Automatic Grade | Automatic |
Certification | CE & ISO-9001 | Weight (KG) | 880 |
Highlight | ZCHONE Tea Bag Packing Machine,Multifunctional Tea Bag Packing Machine,Triangle Tea Bag Packaging Machine |
Packing Machine Type | |
---|---|
Granule Packing Machine | |
Liquid Packing Machine | |
Powder Packing Machine | |
Stand-Up Pouch Packing Machine | |
Vertical Packing Machine | |
Horizontal Packing Machine | |
Tea Bag Machine | |
Coffee Bean Packing Machine | |
Horizontal Packing Machine |
Tea Bag inside and outside Bag Packaging Machine Tea Herbal Tea Tea Small Granules
Technical Specifications:
Model | MD-168 |
Working speed | 30-60 bags/min |
Filling system | VOLUMETRIC |
Bag type | Three sides sealing |
Acceptable bag size |
Inner: 50-70mm * 40-80mm(L X W) Outer: 85-120mm * 70-95mm(L X W) |
Sealing method | Heat sealing |
Weighing range | 0-15ml/bag |
Power | 220V Single phase 50/60Hz |
Weight | 450kg |
Overall dimensions | 1270 * 86 0* 1840mm |
Teabags are more and more popular among young consumers because they are easy to carry, can maintain the natural flavor of the original tea, and can have different nutritional properties according to different tea species. Teabags have become the main consumption method in the tea industry.
This tea bag machine is suitable for disposable packaging of inner and outer bags of small particles such as tea, medicinal tea, tea, etc. The tea bag machine is a heat-sealed edge-sealing, multi-functional automatic tea bag beverage packaging equipment. The main feature of this machine is that the inner and outer bags are formed at one time, which avoids the direct contact between the human hand and the material and improves the efficiency. The inner bag is filter cotton paper, and the outer bag is composite paper. The advantages are: the outer bag adopts photoelectric positioning, the packaging capacity, inner bag, outer bag can be adjusted, and the size of the inner and outer bags can be adjusted according to the different needs of users, so as to achieve the ideal packaging effect, improve the appearance of the product, and make the product value. promote.
This tea bag maker is specially designed for filter paper dipped tea bags such as herbal tea, ground tea, health tea and loose tea, as well as coffee powder and small granules. With VOLUMETRIC weighing and feeding system, the maximum working speed can reach 60 bags/min. Using Mitsubishi PLC and Weinview touch screen, the packaging performance is stable and the operation is convenient.
Q1:Do you have manual or operation video for us to know more about the machine?
Yes, not only manual or operation video, 3D drawing also available to make as per your design,also the video we can make oftesting the material from our packaging machine if your packing goods easier for us to find from our local market.
Q2:Is engineer available to serve oversea?
Yes, but the travel fee is paid by you. So actually to save your cost, we will send you a video of full details machine installation and assist you till the end.
Q3:How can we make sure about the machine quality after we put the order?
Before delivery, we will send you the pictures and videos for you to check the quality, and also you can arrange for quality checking by yourself or by your contacts in China.
Q4:Will you provides the door to door service?
Yes. Please offer us your final destination, we will check with our agent to see if it available, and most of the area is ok for us to clearing and sending in your countries.
