Masala Powder Packing Machine Pillow Pouch Bag Making Packaging Machine
Place of Origin | Guangdong,China |
---|---|
Brand Name | ZCHONE PACK |
Certification | ISO,CE |
Model Number | ZC-VP42 |
Minimum Order Quantity | 1set |
Price | $15,900~$25,900 |
Packaging Details | Standard export wooden case packaging |
Delivery Time | 15 work days |
Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability | 1/sets/15day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xType | Vertical Powder Packaging Machine | Automatic Grade | Automatic |
---|---|---|---|
Core Components | Motor, Pressure Vessel, Pump, PLC, Gear, Bearing, Engine, Gearbox | Application | Food,Chemical,Commodity,Medical,Machinery & Hardware |
Production Capacity | 30bag/min | Weight (KG) | 560 |
Highlight | Commodity Masala Powder Packing Machine,PLC Masala Powder Packing Machine,30bag/min Pillow Pouch Packaging Machine |
Packing Machine Type | |
---|---|
Granule Packing Machine | |
Liquid Packing Machine | |
Powder Packing Machine | |
Stand-Up Pouch Packing Machine | |
Vertical Packing Machine | |
Horizontal Packing Machine | |
Tea Bag Machine | |
Coffee Bean Packing Machine | |
Horizontal Packing Machine |
Masala Powder Packing Machine Pillow Pouch Bag Making Packaging Machine
Machine Specification:
Model | ZC--VP32 | ZC-VP42 | ZC-VP52 | ZC-VP62 |
Packing Speed | 10-50 bags/min | 10-50 包/分钟 | 10-50 包/分钟 | 5~50 bag/min |
Bag Size | (长L) 50-190mm (宽W) 50-150mm | (L) 80-320mm (W) 70-200 mm | (L) 80-320mm (W) 70-200 mm | (L)120-400mm (W)110-300mm |
Bag Making Form | Pillow type back seal bag (roll film for packaging material, automatic bag making by machine is upper sealing, lower sealing and back sealing.) | Pillow bag (optional: stand-up bag, prong bag, punch bag)) | ||
Maximum Packaging Film Width | 320mm | 420mm | 420mm | Max 2500ml |
Measurement Range | 500ml | 1000ml | 1000ml | 620mm |
Membrane Thickness | 0.04-0.12mm | 0.04-0.10mm | 0.04-0.10mm | 0.04-0.14mm |
Complete Set of Air Consumption | 0.8Mpa 0.5m3/min | 0.8Mpa 0.3m³/分 | 0.8Mpa 0.3m³/分 | 0.8Mpa 0.5m3/min |
Total Power/Voltage | 2.5KW/220V 50Hz | 2.7KW/220V 50Hz | 2.7KW/220V 50Hz | 4.2KW/220V 50Hz |
Dimensions | (L)1350*(W)820*(H)1150mm | L1480*W960*H1400mm | L1480*W960*H1400mm | L1964*W1240*H1960mm |
Switchboard Weight | 380kg | 450kg | 450kg | 450kg |
(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)
Masala is a compound seasoning made of turmeric as the main ingredient and a variety of spices. It is spicy and sweet, and has a special aroma. It is mainly used for cooking beef, mutton, chicken, duck, crab, and potatoes. , soup, etc., are commonly used seasonings in Chinese and Western food. In India, Marsala seasoning powder can be put into many foods such as cola milk tea ice cream fruit.
If powder materials such as Masala are packaged by roll film bagging, vertical packaging machines can be selected for fully automated packaging. The powder vertical packaging unit is composed of a closed screw elevator, a screw metering machine, a vertical bag making and packaging machine and a finished product conveyor. It has a series of functions such as automatic feeding, measuring, bag making, filling, sealing, bag cutting, printing, counting, conveying, etc. It is the first choice for improving packaging production efficiency in food, chemical, pharmaceutical and other industries.
Features and Performance
1. High speed and high efficiency.
2. Mitsubishi PLC full computer control system, man-machine interface, large display touch screen, easy to operate.
3. Servo film transport system, horizontal sealing pneumatic control, accurate positioning, excellent performance of the whole machine, and perfect automatic alarm protection function to minimize the loss.
4. High-speed and fully automatic, the whole process of weighing, feeding, bag making, filling, printing date, counting, and finished product output can be automatically completed when the metering device is matched.
5. The food contact parts are made of high-quality 316#/304# stainless steel to ensure food safety.
