Candy canning machine and labeling machine is the key equipment in the candy packaging production line, respectively, responsible for quantitative filling and labeling.

一. Candy canning machine

1. Function type

Weighing filling: for irregular shaped candies (such as soft candy, chocolate beans), the weight accuracy (within ±1%) is controlled by sensors.

Volumetric filling: for uniform particles (e.g. hard candy), dosing by screw or measuring cup, speed up to 200 cans/min.

Vacuum-assisted filling: for fragile candies (e.g. wafers), reducing the risk of breakage.

2. Key parameters

Speed: 50-300 jars/min (depending on jar size and type of candy).

Accuracy: weighing type usually ±0.5g, volumetric type ±1%.

Material: food grade stainless steel (e.g. 304SS), contact parts may be PTFE anti-stick.

3. Selection Note

Compatibility: need to match the tank height (adjustable range usually 50-200mm) and caliber.

Special requirements: such as chocolate need to be equipped with temperature control system (30-45 ℃ constant temperature).

二.Candy labeling machine

1. Labeling type adaptation

Self-adhesive labeling machine: mainstream choice for PET cans/bottles, accuracy ± 0.5mm.

Sleeve labeling machine: for shrink film labels (such as candy gift boxes), need hot air channel shrinkage.

Hot melt adhesive labeling: for paper packaging (e.g. boxed candy), requires adhesive roller temperature control.

2. Core technology

Positioning system: photoelectric sensor detects the position of the can, servo motor controls the timing of label peeling.

Attachment method: Rolling type (flat labeling) or blowing type (for shaped cans).

3. Speed and precision

Standard model: 100-400 pieces/min, high speed line up to 600 pieces/min (such as rotary labeling head).

Repeatability: ±0.3mm (high precision model).

三.common problems to solve

Inaccurate canning: check whether the vibration feeding mechanism is blocked or whether the load cell needs to be calibrated.

Label wrinkling: Adjust the angle of labeling pressure roller (usually 15-30 ° is appropriate), or reduce the speed of the conveyor belt.

Equipment jamming: shaped candy (such as lollipop) need to customize the guide groove to avoid getting stuck in the filling mouth.

Main Parameters

After-sale service:

1. Provide manuals/videos for machine installation, adjustment, setup, and maintenance for your use.

2. If the problem cannot be solved, 24-hour telecommunication or online face-to-face communication is available.

3. SUNCHON engineers and technical engineers can provide machine service in your country.

4. The whole machine is guaranteed for 1 year. During the warranty period, the parts that are not artificially damaged. We will replace it with a new one for you free of charge. The warranty will start after the machine is sent out and we receive the bill of lading.

5. We will provide technical support lifelong and provide accessories persistently.
