Automatic Bag Making Film Roll Packing Machine For Chemical Products

  • Automatic Bag Making Film Roll Packing Machine For Chemical Products
  • Automatic Bag Making Film Roll Packing Machine For Chemical Products
  • Automatic Bag Making Film Roll Packing Machine For Chemical Products
Place of Origin Guangdong，China
Brand Name ZCHONE PACK
Certification ISO，CE
Model Number ZC-VP42
Minimum Order Quantity 1set
Price $11,800~$15,800
Packaging Details Standard export wooden case packaging
Delivery Time 15
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1/sets/15day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Multifunctional Vertical Packing Machine Packaging Type Bags,Pouch
Application Food,Chemical,Commodity,Medical,Machinery & Hardware Automatic Grade Automatic
High Light

Automatic Film Roll Packing Machine

,

Chemical Bag Film Roll Packing Machine
You can tick the products you need and communicate with us in the message board.
Packing Machine Type
Granule Packing Machine
Liquid Packing Machine
Powder Packing Machine
Stand-Up Pouch Packing Machine
Vertical Packing Machine
Horizontal Packing Machine
Tea Bag Machine
Coffee Bean Packing Machine
Horizontal Packing Machine
Leave a Message
Packing Machine Type
Product Description

Automatic Bag Making Film Rolling Packaging Machine Bagging Machine for Bagged Products Packaging Equipment



Machine Specification:



Model ZC--VP32 ZC-VP42 ZC-VP52 ZC-VP62 ZC-VP730 ZC--VP85
Packing Speed 10-50 bags/min 10-50 包/分钟 10-50 包/分钟 5~50 bag/min 5----40 bags/min 10~40 bags/min
Bag Size (L) 50-190mm (W) 50-150mm (L) 80-320mm (W) 70-200 mm (L) 80-320mm (W) 70-200 mm (L)120-400mm (W)110-300mm (L)100-500mm(W) 80-350mm (L)150-500mm (W)150-410mm
Bag Making Form Pillow type back seal bag (roll film for packaging material, automatic bag making by machine is upper sealing, lower sealing and back sealing.) Pillow bag (optional: stand-up bag, prong bag, punch bag)) Roll film for packaging materials, back seal bag Pillow bag, stand-up bag, hole punching bag
Maximum Packaging Film Width 320mm 420mm 420mm Max 2500ml 730mm 850mm
Measurement Range 500ml 1000ml 1000ml 620mm Max2000ML Max 7500ML
Membrane Thickness 0.04-0.12mm 0.04-0.10mm 0.04-0.10mm 0.04-0.14mm 0.04-0.15mm 0.04-0.14m
Complete Set of Air Consumption 0.8Mpa 0.5m3/min 0.8Mpa 0.3m³/分 0.8Mpa 0.3m³/分 0.8Mpa 0.5m3/min 0.8Mpa 0.7m3/min 0.8ps 0.4m3/min
Total Power/Voltage 2.5KW/220V 50Hz 2.7KW/220V 50Hz 2.7KW/220V 50Hz 4.2KW/220V 50Hz 7.0KW 380V 50Hz 6.5KW 220V 50Hz
Dimensions (L)1350*(W)820*(H)1150mm L1480*W960*H1400mm L1480*W960*H1400mm L1964*W1240*H1960mm   L2100*W1640*H2040mm
Switchboard Weight 380kg 450kg 450kg 450kg 680KG 780KG

(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)



The vertical roll film bag-making automatic packaging machine usually consists of a bag packaging machine and a weighing machine. The weighing machine can be a multi-head combination scale, a screw dosimeter or a liquid pump, which can be used to pack granular, powder or liquid materials.



Bag automatic packaging machine is a kind of automatic packaging equipment, which makes the packaging film directly into bags and completes measuring, filling, coding and cutting during the bag making process. The packaging material is usually plastic laminated film, aluminum platinum laminated film, paper bag laminated film, etc.



The bag type automatic packaging machine has the characteristics of high automation, high price, good image and anti-counterfeiting. It is suitable for small-size and large-scale automatic packaging of laundry powder, spices, puffed food and other products. The disadvantage is that it is not convenient to change the packaging specifications.



Automatic Bag Making Film Roll Packing Machine For Chemical Products 0Automatic Bag Making Film Roll Packing Machine For Chemical Products 1
