Automatic Bag Feeding Powder Packing Machine Multi Station Solid Beverage

Place of Origin Guangdong,China
Brand Name ZCHONE PACK
Certification ISO,CE
Model Number ZC-X8200
Minimum Order Quantity 1set
Price $18,000~$29,900
Packaging Details Standard export wooden case packaging
Delivery Time 15 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1set/15day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Multi-Function Packaging Machine Application Food,Chemical,Medical,Beverage,Commodity
Voltage 220V/380V Automatic Grade Automatic
Packaging Material Plastic Warranty 1 Year
Highlight

Automatic Bag Feeding Powder Packing Machine

,

Multi Station Powder Packing Machine

You can tick the products you need and communicate with us in the message board.
Packing Machine Type
Granule Packing Machine
Liquid Packing Machine
Powder Packing Machine
Stand-Up Pouch Packing Machine
Vertical Packing Machine
Horizontal Packing Machine
Tea Bag Machine
Coffee Bean Packing Machine
Horizontal Packing Machine
Leave a Message
Packing Machine Type
Product Description

Automatic Weighing, Measuring and Sealing Powder Packaging Machine



Multi-station bag feeding machine Machine Specification:



Item ZC-X8200 ZC-X8250 ZC-X8300
Packing speed MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc.
Bag size (L)100-300mm (W)70-200mm (L)100-350mm (W)130-250mm (L)150-450mm (W)200-300mm
Bag type Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag
Weighing range 10g-1kg 10g-2kg 10g-3kg

Measurement

accuracy

*≤±0.5~1%, depending on the measuring equipment & materials.
Maximum bag width 200mm 250mm 300mm
Gas consumption 0.8Mpa 0.3m3/min (Supply by user)
Total Powder/Voltage 2.5KW 380V 50/60Hz 2.5KW 380V 50/60Hz 3.7KW 380V 50/60Hz
Air compressor Not less than 1CBM
Dimension L1900*W1400*H1450 L1900*W1400*H1450 L2000*W1500*H1550
Machine Weight 1300kg 1400kg 1500kg
Work flow Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products.

(We can provide you with exclusive customized services according to your needs!)



The eight-station powder packaging machine is a kind of equipment for automatic packaging powder, which can handle multiple packaging tasks at the same time, improving packaging efficiency and production speed. The equipment usually consists of eight workstations, and each workstation can independently complete a series of packaging actions, such as weighing, measuring, filling, sealing, etc.



The eight-station packaging machine usually adopts advanced control system and sensor technology, which can realize high-precision measurement and packaging, which greatly improves the accuracy and stability of the packaging process. At the same time, the eight-station powder packaging machine can also be quickly adjusted and replaced according to different packaging requirements, and is suitable for powder packaging of different types and specifications.



The eight-station powder packaging machine usually has the following advantages:



Efficiency: It can handle multiple packaging tasks at the same time, improving packaging efficiency and production speed.



High precision: high-precision weighing sensor and advanced control system can realize high-precision measurement and packaging.



Good stability: Using advanced control system and sensor technology, automatic control and stable packaging process can be realized.



Strong flexibility: It can be quickly adjusted and replaced according to different packaging requirements, and is suitable for powder packaging of different types and specifications.



In short, the eight-station powder packaging machine is an efficient, stable and flexible automatic packaging equipment, which is suitable for production enterprises that need a large amount of powder packaging.



Features and Performance:



1. Equipped with a variety of automatic diagnosis and automatic alarm safety protection functions to maximize personal safety and reduce material loss.

2. It can be equipped with a remote diagnosis system, which can troubleshoot the machine in the shortest time.

3. It can be equipped with an automatic lubrication system to prolong the life of the machine and reduce labor costs.

4. It can be equipped with a one-key clip adjustment system to quickly adjust the machine according to the width of the packaging bag.

5. The manufacturing process of the whole machine is strict, and the parts are all made of top international brands.

6. In accordance with international safety and hygiene standards, each machine has passed many safety, environmental protection, physical properties and functional tests.

7. Beautiful appearance, simple operation, stable performance and low failure rate.
