Laundry Powder Packaging Machine Powder Pre-made Bag Automatic
The washing powder packaging machine is a device used to automatically package washing powder. It is usually used in industrial production lines to efficiently complete the packaging process of laundry detergent.
The working principle of the washing powder packaging machine is as follows:
Raw material feeding: The washing powder enters the feeding system of the packaging machine through a conveyor belt or other means.
Weighing and measuring: The washing powder packaging machine weighs and measures the washing powder according to the preset weight requirements to ensure that the amount of washing powder in each packaging bag is accurate.
Bag preparation: The washing powder packaging machine automatically cuts a suitable size bag from the roll paper or plastic film, and opens it to prepare the filling of washing powder.
Filling and sealing: The washing powder packaging machine fills the weighed washing powder into the packaging bag, and then seals the packaging bag using heat sealing or other sealing methods.
Label and date printing: Some washing powder packaging machines can also automatically label the packaging bags and print production date, batch number and other information.
Packaging bag inspection: The washing powder packaging machine will conduct quality inspection of the packaging bag, such as checking whether the seal is intact and whether there are foreign objects in the packaging bag, etc.
Discharge and discharge: The packaged laundry detergent bags will be discharged from the discharge port of the packaging machine, and are usually sent to subsequent packaging or transportation links through conveyor belts or other methods.
Machine Specification:
Item | ZC-8200 | ZC-8250 | ZC-8300 |
Packing Speed | Max 60 bags / min | ||
Bag size | L100-300mm | L100-350mm | L150-450mm |
W70-200mm | W130-250mm | W200-300mm | |
Bag Type | Pre-made bags, Stand up bag, Three or Four-side sealed bag, Special-shaped bag | ||
Weighing Range | 10g~1kg | 10~2kg | 10g~3kg |
Measurement Accuracy | ≤±0.5 ~ 1.0%,depend on the measurement equipment and materials | ||
Maximem bag width | 200mm | 250mm | 300mm |
Gas consumption | 0.8Mpa 0.3m³/min | ||
Total power/ voltage | 1.5kw 380v 50/60hz | 1.8kw 380v 50/60hz | 2kw 380v 50/60hz |
Air compressor | Not less than 1 CBM | ||
Dimension | L1900*W1400*H1450mm | L2000*W1500*H1550 | |
Machine Weight | 1300kg | 1500kg |
(We can provide you with exclusive customized services according to your needs!)
