Multifunctional Stand Pouch Packing Machine Pouch Feeding Machine
Place of Origin | Guangdong,China |
---|---|
Brand Name | Guangdong,China |
Certification | ISO,CE |
Model Number | ZC-X8250 |
Minimum Order Quantity | 1set |
Price | $18,000~$36,900 |
Packaging Details | Standard export wooden case packaging |
Delivery Time | 15 work days |
Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability | 1/sets/15day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xType | Multifunctional Packaging Machine | Product Name | Stand-up Pouch Packaging Machine |
---|---|---|---|
Application | Food, Commodity, Medical, Chemical, Machinery & Hardware | Applicable Industries | Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Construction Works , Energy & Mining, Food & Beverage Shops |
Voltage | 220V 380V 50/60HZ | Capacity | Customizable |
High Light | Commodity Stand Pouch Packing Machine,Multifunctional Stand Pouch Packing Machine,60HZ Stand Up Pouch Machine |
Packing Machine Type | |
---|---|
Granule Packing Machine | |
Liquid Packing Machine | |
Powder Packing Machine | |
Stand-Up Pouch Packing Machine | |
Vertical Packing Machine | |
Horizontal Packing Machine | |
Tea Bag Machine | |
Coffee Bean Packing Machine | |
Horizontal Packing Machine |
Stand-Up Pouch Packaging Machine Multifunctional Pouch Feeding Machine Multi-Station High-Speed Operation
Machine Specification:
Item | ZC-X8200 | ZC-X8250 | ZC-X8300 |
Packing speed | MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc. | ||
Bag size | (L)100-300mm (W)70-200mm | (L)100-350mm (W)130-250mm | (L)150-450mm (W)200-300mm |
Bag type | Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag | ||
Weighing range | 10g-1kg | 10g-2kg | 10g-3kg |
Measurement accuracy |
*≤±0.5~1%, depending on the measuring equipment & materials. | ||
Maximum bag width | 200mm | 250mm | 300mm |
Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | ||
Total Powder/Voltage | 2.5KW 380V 50/60Hz | 2.5KW 380V 50/60Hz | 3.7KW 380V 50/60Hz |
Air compressor | Not less than 1CBM | ||
Dimension | L1900*W1400*H1450 | L1900*W1400*H1450 | L2000*W1500*H1550 |
Machine Weight | 1300kg | 1400kg | 1500kg |
Work flow | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. |
(We can provide you with exclusive customized services according to your needs!)
Stand-up pouch packing machine is a high speed packaging machine. It can pack the products in different sizes, shapes and colors into pouches. The product is packed by using this machine without any human intervention. This type of packaging machines are used to pack the products such as candy, biscuits, chips, cookies or other food items.
There are also many styles of stand-up pouches themselves, such as: stand-up pouches with zipper, stand-up pouches with suction nozzles, stand-up pouches with holes, our multi-station pre-med pouch packaging machine can perfectly pack various types of stand-up pouches. The fully automatic multi-station packaging machine can automatically take bags, print the date, open bags, measure signals to the metering device and blank, seal, and output. , fully automatic packaging of solid, powder and other materials.
The main optional configurations are material measuring and filling machine, working platform, weight sorting scale, material hoist, vibrating feeder, finished product conveying hoist, metal detector,etc.
After-sale service:
1. Provide manuals/videos for machine installation, adjustment, setup, and maintenance for your use.
2. If the problem cannot be solved, 24-hour telecommunication or online face-to-face communication is available.
3. SUNCHON engineers and technical engineers can provide machine service in your country.
4. The whole machine is guaranteed for 1 year. During the warranty period, the parts that are not artificially damaged. We will replace it with a new one for you free of charge. The warranty will start after the machine is sent out and we receive the bill of lading.
5.We will provide technical support lifelong and provide accessories persistently.
