Transparent Composite Bag Stand Up Packing Machine Aluminum Foil Composite Bag
Place of Origin | Guangdong,China |
---|---|
Brand Name | ZCHONE PACK |
Certification | ISO,CE |
Model Number | ZC-8200 |
Minimum Order Quantity | 1set |
Price | $18,000~$36,900 |
Packaging Details | Standard export wooden case packaging |
Delivery Time | 15 work days |
Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability | 1/sets/15day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xType | Multifunctional Packaging Machine | Product Name | Multi-station Packaging Machine |
---|---|---|---|
Weight (KG) | 1300 | Function | FILLING, Labeling, Sealing |
Voltage | 110V 220V 380V 50hz/60hz | Warranty | 1 Year |
High Light | 2.5KW Stand Up Packing Machine,3.7KW Stand Up Packing Machine,Stand Up Pouch Filling And Sealing Machin |
Packing Machine Type | |
---|---|
Granule Packing Machine | |
Liquid Packing Machine | |
Powder Packing Machine | |
Stand-Up Pouch Packing Machine | |
Vertical Packing Machine | |
Horizontal Packing Machine | |
Tea Bag Machine | |
Coffee Bean Packing Machine | |
Horizontal Packing Machine |
Stand Up Pouches Packaging Machine Transparent Composite Bag Aluminum Foil Composite Bag Granular Powder Packaging
Machine Specification:
Item | ZC-X8200 | ZC-X8250 | ZC-X8300 |
Packing speed | MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc. | ||
Bag size | (L)100-300mm (W)70-200mm | (L)100-350mm (W)130-250mm | (L)150-450mm (W)200-300mm |
Bag type | Pre-mede bags, Stand-up bag, four-side sealed bag, three-side sealed bag, special-shaped bag | ||
Weighing range | 10g-1kg | 10g-2kg | 10g-3kg |
Measurement accuracy |
*≤±0.5~1%, depending on the measuring equipment & materials. | ||
Maximum bag width | 200mm | 250mm | 300mm |
Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | ||
Total Powder/Voltage | 2.5KW 380V 50/60Hz | 2.5KW 380V 50/60Hz | 3.7KW 380V 50/60Hz |
Air compressor | Not less than 1CBM | ||
Dimension | L1900*W1400*H1450 | L1900*W1400*H1450 | L2000*W1500*H1550 |
Machine Weight | 1300kg | 1400kg | 1500kg |
Work flow | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. |
(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)
Stand-up pouch packaging is mainly used in the food industry. Fruit juice drinks, sports drinks, bottled drinking water, absorbent jelly, condiments and other products have stand-up pouch packaging products, some washing products, daily cosmetics, medical supplies and other products. applications are also increasing. The stand-up bag can be perfectly matched with other processes, such as zippered as an outer packaging bag. This type of food packaging bag is often used in nuts, preserved fruit, dried fruit, coffee, tea, etc.; if a suction nozzle is added, this type of food packaging bag Often used in chicken essence, beverages, sugar, etc.
Stand-up pouches are generally fully automated packaging using a bag-feeding packaging machine. At present, the automatic bag-feeding packaging machines mainly include: multi-station packaging machine, single-station packaging machine, horizontal packaging machine, etc.
Among them, the multi-station packaging machine has the characteristics of simple operation and fast packaging speed, and is the first choice of many manufacturers. The multi-station bag-type packaging machine replaces manual packaging, and realizes packaging automation for large enterprises and small and medium-sized enterprises. The mechanical grasping equipment will automatically pick up the bag, print the date, open the bag, measure the signal to the metering device and drop the material. Seal, export. The main optional configurations are material measuring and filling machine, working platform, weight sorting scale, material hoist, vibrating feeder, finished product conveying hoist, metal detector, etc.
Q1:Do you have manual or operation video for us to know more about the machine?
Yes, not only manual or operation video, 3D drawing also available to make as per your design,also the video we can make oftesting the material from our packaging machine if your packing goods easier for us to find from our local market.
Q2:Is engineer available to serve oversea?
Yes, but the travel fee is paid by you. So actually to save your cost, we will send you a video of full details machine installation and assist you till the end.
Q3:How can we make sure about the machine quality after we put the order?
Before delivery, we will send you the pictures and videos for you to check the quality, and also you can arrange for quality checking by yourself or by your contacts in China.
Q4:Will you provides the door to door service?
Yes. Please offer us your final destination, we will check with our agent to see if it available, and most of the area is ok for us to clearing and sending in your countries.
