Bag Milk Packaging Machine Liquid Paste Multi-function Packaging Machine

Place of Origin Guangdong,China
Brand Name ZCHONE PACK
Certification ISO,CE
Model Number ZC-200
Minimum Order Quantity 1set
Price $18,000~$36,900
Packaging Details Standard export wooden case packaging
Delivery Time 15 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1set/15day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Multifunctional Packaging Machine Product Name Rotary Packaging Machine
Function FILLING, Labeling, Sealing Key Selling Points Automatic
Maximum Bag Width 200mm Warranty 1 Year
Highlight

Liquid Paste Packaging Machine

,

Bag milk Packaging Machine

,

Multi-function Liquid Packaging Machine

You can tick the products you need and communicate with us in the message board.
Packing Machine Type
Granule Packing Machine
Liquid Packing Machine
Powder Packing Machine
Stand-Up Pouch Packing Machine
Vertical Packing Machine
Horizontal Packing Machine
Tea Bag Machine
Coffee Bean Packing Machine
Horizontal Packing Machine
Leave a Message
Packing Machine Type
Product Description

Bag milk Packaging Machine Liquid Paste Multi-function Packaging Machine



Bag milk packaging machines are equipment used to automatically package milk bag products. These devices are usually used on production lines and can automatically complete functions such as filling, sealing, date printing, etc. This machine can greatly improve production efficiency and ensure the quality and hygiene standards of product packaging.



Common bag milk packaging machines usually include the following key features:



Automatic control system, which is used to monitor and adjust the packaging process.



Filling system, which can accurately control the filling amount of milk.



Sealing system, which is used to seal the packaging bag.



Date printing system, which can print the production date and other necessary information on the package.



Safety system, which ensures the safety of operators and avoids accidents.



These devices usually differ according to different production needs, and the appropriate bag milk packaging machine can be selected according to the scale of the production line and packaging requirements.



Machine Specification:



Item ZC-X8200 ZC-X8250 ZC-X8300
Packing speed MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc.
Bag size (L)100-300mm (W)70-200mm (L)100-350mm (W)130-250mm (L)150-450mm (W)200-300mm
Bag type Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag
Weighing range 10g-1kg 10g-2kg 10g-3kg

Measurement

accuracy

*≤±0.5~1%, depending on the measuring equipment & materials.
Maximum bag width 200mm 250mm 300mm
Gas consumption 0.8Mpa 0.3m3/min (Supply by user)
Total Powder/Voltage 2.5KW 380V 50/60Hz 2.5KW 380V 50/60Hz 3.7KW 380V 50/60Hz
Air compressor Not less than 1CBM
Dimension L1900*W1400*H1450 L1900*W1400*H1450 L2000*W1500*H1550
Machine Weight 1300kg 1400kg 1500kg
Work flow Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products.

(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)





Bag Milk Packaging Machine Liquid Paste Multi-function Packaging Machine 0





Bag Milk Packaging Machine Liquid Paste Multi-function Packaging Machine 1



Scope of application of pet food bag packing machine: dog food, cat food, rabbit food, pet freeze-dried, dried small fish, yogurt cubes, etc.



Applicable bag quality: PE composite film, aluminum foil film, aluminized film and other composite material films.



Applicable bag types: stand-up bags, zipper bags, slanted-mouth stand-up bags, flat bags (three-side sealing, four-side sealing, handbag, back-sealing bag, hemming bag, etc.)



Bag Milk Packaging Machine Liquid Paste Multi-function Packaging Machine 2
