Multifunctional Automatic Granule Packing Machine Multi Station
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Multi-Function Packaging Machine | Application | Food, Commodity |
|---|---|---|---|
| Packaging Type | Stand-up Pouch, Bags, Pouch | Automatic Grade | Automatic |
| Warranty | 1 Year | Warranty Of Core Components | 1 Year |
| Highlight | Multifunctional Granule Packing Machine,2.5KW Granule Packing Machine,Multi Station Automatic Granule Packing Machine |
||
You can tick the products you need and communicate with us in the message board.
| Packing Machine Type | |
|---|---|
| Granule Packing Machine | |
| Liquid Packing Machine | |
| Powder Packing Machine | |
| Stand-Up Pouch Packing Machine | |
| Vertical Packing Machine | |
| Horizontal Packing Machine | |
| Tea Bag Machine | |
| Coffee Bean Packing Machine | |
| Horizontal Packing Machine |
Product Description
Multifunctional automatic granule packing machine Multi-station vertical bag-feeding packaging machine
Machine Specification:
| Item | ZC-X8200 | ZC-X8250 | ZC-X8300 |
| Packing speed | MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc. | ||
| Bag size | (L)100-300mm (W)70-200mm | (L)100-350mm (W)130-250mm | (L)150-450mm (W)200-300mm |
| Bag type | Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag | ||
| Weighing range | 10g-1kg | 10g-2kg | 10g-3kg |
|
Measurement accuracy |
*≤±0.5~1%, depending on the measuring equipment & materials. | ||
| Maximum bag width | 200mm | 250mm | 300mm |
| Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | ||
| Total Powder/Voltage | 2.5KW 380V 50/60Hz | 2.5KW 380V 50/60Hz | 3.7KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM | ||
| Dimension | L1900*W1400*H1450 | L1900*W1400*H1450 | L2000*W1500*H1550 |
| Machine Weight | 1300kg | 1400kg | 1500kg |
| Work flow | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. | ||
| Applicable scope | Granular type: crystal monosodium glutamate, granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer, etc | ||
(We can provide you with exclusive customized services according to your needs!)
The modern industry is becoming more and more intelligent and mechanized, and more and more large and small factories on the market want to realize the idea of replacing labor with machines. Therefore, more and more companies on the market have developed packing machines and used automatic packing machines to reduce labor costs. Packaging costs, so as to achieve the idea of saving labor and improving production efficiency, the ordinary packaging machines on the market can basically achieve fully automatic packaging, one-key packaging, automatic weighing, blanking, packaging, automatic sealing, good sealing, The packaging speed reaches 50-70 packs per minute and the price is around 20,000-40,000.
There are many types of automatic granule packaging machines to choose from, which are generally divided into: single-station granule packing machine, eight-station granule packing machine, horizontal granule packaging machine, vertical granule packaging machine, stand-up pouch granule packaging machine, etc. We can According to your product needs, we will provide you with suitable packaging machine products.
Our fully automatic granule packing machine:
1. It can automatically complete pouch making, measuring, cutting, sealing, slitting, measuring, printing and other functions. (can be configured according to customer needs)
2. Adopt microcomputer controller, intelligent touch screen interface, parameters can be easily adjusted, drive stepper motor to control bag length, stable performance, convenient adjustment, accurate monitoring function, automatic fault alarm one-key diagnosis, fault display at a glance.
3. The sealing tool is flat and beautiful, with clear lines, firm and airtight.
4. Stainless steel cutter, clean and neat, no jamming.
5. Unloading materials in an orderly manner, without clipping materials, it can automatically identify when the materials are insufficient, and prompt the alarm system.
