Dried Fruit Nut Granule Multihead Scale Multifunctional Automatic 304/316 Stainless Steel Food Grade Packaging Machine

Place of Origin Guangdong,China
Brand Name ZCHONE PACK
Certification ISO,CE
Model Number ZC-X8300
Minimum Order Quantity 1set
Price $18,000~$36,900
Packaging Details Standard export wooden case packaging
Delivery Time 15 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1set/15day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Multifunctional Packaging Machine Product Name Multi-station Packaging Machine With Multi-head Scale
Material Stainless Steel Warranty Period 1 Year
After Warranty Service1 Video Technical SupportOnline Support After Warranty Service2 Field Maintenance And Repair Service
You can tick the products you need and communicate with us in the message board.
Packing Machine Type
Granule Packing Machine
Liquid Packing Machine
Powder Packing Machine
Stand-Up Pouch Packing Machine
Vertical Packing Machine
Horizontal Packing Machine
Tea Bag Machine
Coffee Bean Packing Machine
Horizontal Packing Machine
Leave a Message
Packing Machine Type
Product Description

Dried Fruit Nut Granule Multihead Scale Multifunctional Automatic 304/316 Stainless Steel Food Grade Packaging Machine



Fig packaging machine is a fully automatic packaging machine system consisting of eight-station host + multi-head combination scale + material hoist



Working principle: Fig packaging machine usually completes the packaging process through a series of automated steps. This may include steps such as weighing, metering, filling, sealing and marking.



Packing method: Fig packaging machine can be used for packaging of various bag types, depending on the size and type of the packaging bag.



Scope of application: Fig packaging machine is generally suitable for the food processing industry and can be used to package fresh figs, dried fruits, preserved fruits and other products.



Degree of automation: Some high-end fig packaging machines may have highly automated functions, including automatic adjustment, fault diagnosis and production data tracking.



Cleaning and maintenance: Keeping the fig packaging machine clean and regularly maintained is very important to ensure the normal operation of the equipment, and also helps to ensure product quality and food safety.



Cost and performance: The cost and performance of the fig packaging machine will vary depending on the equipment model, brand, function and other factors. When choosing equipment, it is necessary to comprehensively consider factors such as production needs, budget and technical support.



Accurate weighing: The multi-head weighing system can accurately weigh each product according to the set requirements to ensure the accurate weight of each package of figs.



Efficient production: Through the multi-head weighing system, the equipment can achieve efficient production, reduce manual intervention, and improve production efficiency.



Eight-station packing machine Machine Specification:



Item ZC-X8200 ZC-X8250 ZC-X8300
Packing speed MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc.
Bag size (L)100-300mm (W)70-200mm (L)100-350mm (W)130-250mm (L)150-450mm (W)200-300mm
Bag type Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag
Weighing range 10g-1kg 10g-2kg 10g-3kg

Measurement

accuracy

*≤±0.5~1%, depending on the measuring equipment & materials.
Maximum bag width 200mm 250mm 300mm
Gas consumption 0.8Mpa 0.3m3/min (Supply by user)
Total Powder/Voltage 2.5KW 380V 50/60Hz 2.5KW 380V 50/60Hz 3.7KW 380V 50/60Hz
Air compressor Not less than 1CBM
Dimension L1900*W1400*H1450 L1900*W1400*H1450 L2000*W1500*H1550
Machine Weight 1300kg 1400kg 1500kg
Work flow Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products.

(We can provide you with exclusive customized services according to your needs!)
