Solid Granules Multi-functional Automatic Multi-station Bag Packing Machine

Place of Origin Guangdong,China
Brand Name ZCHONE PACK
Certification ISO,CE
Model Number ZC-X8300
Minimum Order Quantity 1set
Price $18,000~$36,900
Packaging Details Standard export wooden case packaging
Delivery Time 15 work days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1set/15day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Multifunctional Packaging Machine Product Name Multi-station Packaging Machine With Multi-head Scale
Material Stainless Steel Warranty Period 1 Year
After Warranty Service1 Video Technical SupportOnline Support After Warranty Service2 Field Maintenance And Repair Service
Highlight

Automatic Granule Packing Machine

,

Multi-station Granule Packing Machine

,

Multi-functional Granule Packing Machine

You can tick the products you need and communicate with us in the message board.
Packing Machine Type
Granule Packing Machine
Liquid Packing Machine
Powder Packing Machine
Stand-Up Pouch Packing Machine
Vertical Packing Machine
Horizontal Packing Machine
Tea Bag Machine
Coffee Bean Packing Machine
Horizontal Packing Machine
Leave a Message
Packing Machine Type
Product Description

Solid Granules Multi-functional Automatic Multi-station Bag Packing Machine

Solid particle bag-feeding packaging machine is a packaging equipment widely used in food, cosmetics, pharmaceuticals and other industries. It can effectively put solid particle items into bags, seal and cut them, and ensure the quality and hygiene of the products. These devices are usually used to pack small particles such as nuts, candies, coffee beans, tablets, etc.



The working principle of solid particle bag-feeding packaging machine is usually as follows: first, the solid particle items are loaded into the storage bin of the equipment; then, the equipment quantitatively puts the particle items into the packaging bag by automatic or manual means; then, the packaging bag is sealed, and heat sealing or cold sealing can be selected to ensure the sealing and freshness of the product; finally, the packaging bag is cut and output and is ready to be put on the market.



The advantages of solid particle bag-feeding packaging machine include:



High degree of automation, which can improve production efficiency and reduce labor costs;

The sealing and cutting operations during the packaging process are accurate, the packaging effect is beautiful, and the product grade is improved;

It can be flexibly adjusted according to the shape and size of the product, and has a wide range of applicability;

The material and size of the packaging bag can be customized according to demand to meet different market needs.

It should be noted that the solid particle bag packaging machine should be regularly maintained and cleaned during use to ensure the normal operation of the equipment and the packaging effect.



Eight-station packing machine Machine Specification:



Item ZC-X8200 ZC-X8250 ZC-X8300
Packing speed MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc.
Bag size (L)100-300mm (W)70-200mm (L)100-350mm (W)130-250mm (L)150-450mm (W)200-300mm
Bag type Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag
Weighing range 10g-1kg 10g-2kg 10g-3kg

Measurement

accuracy

*≤±0.5~1%, depending on the measuring equipment & materials.
Maximum bag width 200mm 250mm 300mm
Gas consumption 0.8Mpa 0.3m3/min (Supply by user)
Total Powder/Voltage 2.5KW 380V 50/60Hz 2.5KW 380V 50/60Hz 3.7KW 380V 50/60Hz
Air compressor Not less than 1CBM
Dimension L1900*W1400*H1450 L1900*W1400*H1450 L2000*W1500*H1550
Machine Weight 1300kg 1400kg 1500kg
Work flow Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products.

(We can provide you with exclusive customized services according to your needs!)
