Seasonings Packaging Machine Fennel Anise Spice Brine Pre-made Bag Automatic Packaging Machine
The eight-station fully automatic dry chili packaging machine is an efficient and intelligent packaging equipment specially used for quantitative packaging of dry chili. The equipment usually has the following characteristics and functions:
1. Main features
✅ Multi-station design: Adopts an eight-station rotary structure to improve packaging efficiency and stability.
✅ Fully automatic operation: realizes automatic feeding, weighing, filling, sealing, coding, exhaust and other functions, reducing manual intervention.
✅ Applicable to a variety of packaging materials: supports a variety of packaging materials such as plastic film, composite film, aluminum foil bag, etc.
✅ High-precision weighing system: equipped with electronic scale or multi-head combination scale to ensure the accuracy of packaging weight.
✅ Intelligent control system: equipped with PLC touch screen, supports multiple parameter settings, simple and intuitive operation.
✅ Safety protection design: with emergency shutdown, fault alarm, lack of material detection and other functions to improve production safety.
2. Workflow
Automatic feeding → 2. Weighing and metering → 3. Bag picking and placing → 4. Filling materials → 5. Heat sealing → 6. Coding and printing → 7. Finished product output
3. Scope of application
✅ Dried chili peppers (whole chili peppers, chili pepper segments, chili powder)
✅ Granular foods (peppercorns, star anise, cumin, etc.)
✅ Condiments (hot pot base, chili powder)
✅ Other agricultural products (rice, beans, etc.)
4. Optional functions
Nitrogen filling device (extends shelf life)
Dust removal device (applicable to chili powder)
Automatic inkjet printer (prints production date and other information)
Machine Specification:
Item | ZC-X8200 | ZC-X8250 | ZC-X8300 |
Packing speed | MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc. | ||
Bag size | (L)100-300mm (W)70-200mm | (L)100-350mm (W)130-250mm | (L)150-450mm (W)200-300mm |
Bag type | Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag | ||
Weighing range | 10g-1kg | 10g-2kg | 10g-3kg |
Measurement accuracy |
*≤±0.5~1%, depending on the measuring equipment & materials. | ||
Maximum bag width | 200mm | 250mm | 300mm |
Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | ||
Total Powder/Voltage | 2.5KW 380V 50/60Hz | 2.5KW 380V 50/60Hz | 3.7KW 380V 50/60Hz |
Air compressor | Not less than 1CBM | ||
Dimension | L1900*W1400*H1450 | L1900*W1400*H1450 | L2000*W1500*H1550 |
Machine Weight | 1300kg | 1400kg | 1500kg |
Work flow | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. | ||
Applicable scope | Granular type: crystal monosodium glutamate, granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer, etc |
(We can provide you with exclusive customized services according to your needs!)
