Noodle Packaging Machine Eight-Station Rotary High-Speed 316/304 Stainless Steel Food Packaging Machine Anti-rust Oxidation

  • Noodle Packaging Machine Eight-Station Rotary High-Speed 316/304 Stainless Steel Food Packaging Machine Anti-rust Oxidation
  • Noodle Packaging Machine Eight-Station Rotary High-Speed 316/304 Stainless Steel Food Packaging Machine Anti-rust Oxidation
  • Noodle Packaging Machine Eight-Station Rotary High-Speed 316/304 Stainless Steel Food Packaging Machine Anti-rust Oxidation
Place of Origin Guangdong，China
Brand Name ZCHONE PACK
Certification ISO，CE
Model Number ZC-8200
Minimum Order Quantity 1set
Price $18000
Packaging Details Standard export wooden case packaging
Delivery Time 15
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1/sets/15day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Automatic Packaging Machine Product Name Food Granule Multi-station Packaging Machine
Dimension(L*W*H) L1900*W1400*H1450 Weight (KG) 1300
Voltage 110V 220V 380V 50hz/60hz Production Capacity 20bag/min, 50bag/min, 30bag/min
You can tick the products you need and communicate with us in the message board.
Packing Machine Type
Granule Packing Machine
Liquid Packing Machine
Powder Packing Machine
Stand-Up Pouch Packing Machine
Vertical Packing Machine
Horizontal Packing Machine
Tea Bag Machine
Coffee Bean Packing Machine
Horizontal Packing Machine
Leave a Message
Packing Machine Type
Product Description

Noodle Packaging Machine Eight-Station Rotary High-Speed 316/304 Stainless Steel Food Packaging Machine Anti-rust Oxidation



Noodle packaging machine is a kind of equipment specially used for automatic packaging of noodles, which is widely used in food processing industry. It can measure, pack, seal and pack noodles efficiently and accurately, improve production efficiency, reduce labor costs, and ensure the hygiene and consistency of packaging.



Main functions

Automatic measurement: Automatically measure noodles according to preset weight or quantity.



Automatic bagging: Put the measured noodles into the packaging bag.



Automatic sealing: Heat or cold seal the packaging bag to ensure sealing.



Coding function: Print production date, batch number and other information on the packaging.



Automatic conveying: Convey the packaged products to the designated location for subsequent boxing or stacking.



Equipment features

High efficiency: Automated operation, fast packaging speed, suitable for large-scale production.



Precision: Accurate measurement, reduce errors, and ensure that the weight of each bag of noodles is consistent.



Hygiene: Food-grade materials are used to meet food safety standards.



Flexibility: It can adapt to noodles and packaging bags of different specifications.



Easy operation: PLC control system is adopted, the operation interface is friendly and easy to maintain.



Main components

Measuring device: used to accurately measure the weight or quantity of noodles.



Packaging material conveying system: convey packaging materials (such as plastic film or paper bags) to the specified location.



Sealing device: seal the packaging bag to ensure sealing.



Coding machine: print relevant information on the package.



Control system: PLC or microcomputer control to achieve automatic operation.



Conveyor belt: convey the packaged products to the next process.



Application scenario

Noodle packaging machines are widely used in food processing plants, noodle production lines, grain and oil processing enterprises, etc., especially suitable for production environments that require large-scale and high-efficiency packaging.



Machine Specification:

Item ZC-X8200 ZC-X8250 ZC-X8300
Packing speed MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc.
Bag size (L)100-300mm (W)70-200mm (L)100-350mm (W)130-250mm (L)150-450mm (W)200-300mm
Bag type Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag
Weighing range 10g-1kg 10g-2kg 10g-3kg

Measurement

accuracy

 *≤±0.5~1%, depending on the measuring equipment & materials.
Maximum bag width 200mm 250mm 300mm
Gas consumption 0.8Mpa 0.3m3/min (Supply by user)
Total Powder/Voltage 2.5KW 380V 50/60Hz 2.5KW 380V 50/60Hz 3.7KW 380V 50/60Hz
Air compressor Not less than 1CBM
Dimension L1900*W1400*H1450 L1900*W1400*H1450 L2000*W1500*H1550
Machine Weight 1300kg 1400kg 1500kg
Work flow Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products.
Applicable scope Granular type: crystal monosodium glutamate, granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer, etc

(We can provide you with exclusive customized services according to your needs!)
