Durable Small Food Pouches Packing Machine 50/60HZ Automatic
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Place Of Origin | Foshan China | Product Name | Spout Packing Machine |
|---|---|---|---|
| Application | Beverage, Liquid & Juice | Packaging Material | Plastic |
| Voltage | 220V 380V 50/60HZ | Key Selling Points | Automatic |
| High Light | Small Pouches Packing Machine,50HZ Pouches Packing Machine,60HZ Small Food Packaging Machine |
||
You can tick the products you need and communicate with us in the message board.
| Packing Machine Type | |
|---|---|
| Granule Packing Machine | |
| Liquid Packing Machine | |
| Powder Packing Machine | |
| Stand-Up Pouch Packing Machine | |
| Vertical Packing Machine | |
| Horizontal Packing Machine | |
| Tea Bag Machine | |
| Coffee Bean Packing Machine | |
| Horizontal Packing Machine |
Product Description
Pouches Packing Machine Small Automatic Food Packaging Machine
Machine Specification:
| Item | ZC-X8200 | ZC-X8250 | ZC-X8300 |
| Packing speed | MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc. | ||
| Bag size | (L)100-300mm (W)70-200mm | (L)100-350mm (W)130-250mm | (L)150-450mm (W)200-300mm |
| Bag type | Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag | ||
| Weighing range | 10g-1kg | 10g-2kg | 10g-3kg |
|
Measurement accuracy |
*≤±0.5~1%, depending on the measuring equipment & materials. | ||
| Maximum bag width | 200mm | 250mm | 300mm |
| Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | ||
| Total Powder/Voltage | 2.5KW 380V 50/60Hz | 2.5KW 380V 50/60Hz | 3.7KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM | ||
| Dimension | L1900*W1400*H1450 | L1900*W1400*H1450 | L2000*W1500*H1550 |
| Machine Weight | 1300kg | 1400kg | 1500kg |
| Work flow | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. | ||
(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)
The packaging field of small automatic food packaging machine is very wide, involving food, beverage, medicine, daily necessities, chemical and other industries, among which the main one is the food and beverage industry with a large market.
The bag-type packaging machine replaces manual packaging and realizes packaging automation for large enterprises and small and medium-sized enterprises. The mechanical grasping equipment will automatically take the bag, print the date, open the bag, measure the signal to the metering device and blank, seal, output.
Small automatic food packaging and product features:
1. Frequency conversion speed regulation, small automatic food packaging machine uses frequency conversion speed regulation device, and the speed can be adjusted at will within the specified range.
2. Easy to operate, using PLC control, equipped with touch screen man-machine interface control system, easy to operate.
3. Safety device, when the working air pressure is abnormal or the heating tube fails, it will alarm.
4. With the horizontal bag feeding method, the bag storage device can store more packaging bags, which has lower requirements on the quality of the bags, and the rate of bag separation and bag loading is high.
5. The equipment part of the horizontal packaging machine adopts imported engineering plastic bearings, which does not require oiling and reduces the pollution to materials.
6. The zipper bag opening mechanism is specially designed for the characteristics of the zipper bag mouth to avoid deformation or damage of the bag mouth.
