Multi Function Vacuum Packing Machine Nuts Pouch Packaging Equipment
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Certification | ISO，CE | Type | Multi-Function Packaging Machine |
|---|---|---|---|
| Applicable Product | Nuts, Cashews, Candies, Pistachios, Coffee Beans, Tea, Cookies, Popcorn, Snacks, Food, Jelly, Chocolate, Etc. | Core Components | Motor, Pressure Vessel, Pump, PLC, Gear, Bearing, Engine, Gearbox |
| Production Capacity | 20bag/min, 50bag/min, 30bag/min | ||
| High Light | Multi Function Vacuum Packing Machine,Nuts Pouch Vacuum Packing Machine |
||
You can tick the products you need and communicate with us in the message board.
| Machine Components | Equipped With Groducts | |
|---|---|---|
| Host | Eight-Position Automatic Premade Pouch Packing Machine | |
| Measuring Equipments | Multi Heads Combination Weigher | |
| Cinveyor | Z Type Bucket Conveyor | |
| Platform | Supporting Platform |
Product Description
Vacuum Packing Machine Pouch Packaging Product Packaging Machine
Machine Specification:
| Item | ZC-X8200 | ZC-X8250 | ZC-X8300 |
| Packing speed | MAX 60 bags/min,depending on the quality of the packaging film,packaging materials packaging weight etc. | ||
| Bag size | (L)100-300mm (W)70-200mm | (L)100-350mm (W)130-250mm | (L)150-450mm (W)200-300mm |
| Bag type | Pre-mede bags,Stand-up bag,four-side sealed bag,three-side sealed bag,special-shaped bag | ||
| Weighing range | 10g-1kg | 10g-2kg | 10g-3kg |
|
Measurement accuracy |
*≤±0.5~1%, depending on the measuring equipment & materials. | ||
| Maximum bag width | 200mm | 250mm | 300mm |
| Gas consumption | 0.8Mpa 0.3m3/min (Supply by user) | ||
| Total Powder/Voltage | 2.5KW 380V 50/60Hz | 2.5KW 380V 50/60Hz | 3.7KW 380V 50/60Hz |
| Air compressor | Not less than 1CBM | ||
| Dimension | L1900*W1400*H1450 | L1900*W1400*H1450 | L2000*W1500*H1550 |
| Machine Weight | 1300kg | 1400kg | 1500kg |
| Work flow | Giving bag→Coding→Opening bag(or Open zipper bag)→Filling→ Auxiliary→Exhaust→Heat sealing→Forming and output products. | ||
(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)
The bag-type automatic packaging machine usually consists of a bag-type machine and a weighing machine. The weighing machine can be a multi-head combination scale, a screw dosimeter or a liquid pump, which can be used to pack granule, powder or liquid materials.The working principle of the bag-type automatic packaging machine is to use the manipulator to take the bag, open the bag, cover the bag, and seal the user's prefabricated bag, and complete the functions of filling and coding under the coordinated control of the computer to realize the automatic packaging of the prefabricated bag.
The bag-type automatic packaging machine is characterized by manipulators replacing manual bags, which can effectively reduce bacterial contamination in the packaging process and improve the level of automation. It is suitable for small-scale and large-scale automatic packaging of food, condiment and other products. The disadvantage is that premade bags need to remove static electricity, otherwise it is easy to take double bags and open bags. It is also inconvenient for the machine to change the packaging specifications.
